护坡砖正确的施工流程
护坡砖的使用可以有效的防护水源对土地的侵蚀，减少路面不平整的现象发生。因此在很多水流附近都会有护坡砖的身影，还会在道路两旁种上绿植，同样护坡砖也被使用到，其独特的结构使得在控制水流方面非常不错。那么山东护坡砖的施工流程是什么呢？
The use of slope protection bricks can effectively protect the soil from water erosion and reduce the occurrence of uneven pavement. Therefore, there are slope protection bricks around many water flows, and green plants are planted on both sides of the road. Similarly, slope protection bricks are also used, and their unique structure makes them very good at controlling water flow. So what is the construction process of slope protection bricks in Shandong?
1、挖掘边沿基坑，坑底填充适当的材料并震实，砌筑上下沿挡板，挡板顶标高砌与联锁护坡底标高一平。
1. Excavate the edge of the foundation pit, fill the pit bottom with appropriate materials and vibrate it firmly. Build the upper and lower edge baffles, and the top elevation of the baffles shall be level with the elevation of the interlocking slope protection bottom.
2、在已经完成的基础面上铺设土工布或者级配碎石。
2. Lay geotextile or graded crushed stone on the completed foundation surface.
3、从下边沿开始联锁铺设三行联锁式护坡砖，砖的长度方向沿着水流方向反向铺设，下沿..行砖有一般砌入趾墙中，与毛石或混凝土趾墙相锚固，下沿的第二行联锁砖的下边沿与趾墙墙面相交。
3. Interlock and lay three rows of interlocking slope protection bricks starting from the lower edge, with the length direction of the bricks being laid in the reverse direction of the water flow direction, and the lower edge Row bricks are generally built into the toe wall and anchored to the rubble or concrete toe wall. The lower edge of the second row of interlocking bricks at the lower edge intersects the toe wall surface.
4、砌筑下沿趾墙，用混凝土或者毛石混凝土将剩余部分的趾墙连同锚固入趾墙的联锁砖一起砌筑，使得趾墙符合设计要求的尺寸。
4. Build the lower toe wall, and use concrete or rubble concrete to build the remaining part of the toe wall together with interlocking bricks anchored into the toe wall, so that the toe wall meets the dimensions required by the design.
5、从左下角铺设其他护土砖，铺设方向与趾墙平行，不得垂直趾墙方向铺设，以防产生累计误差，影响铺设质量。
5. Lay other retaining bricks from the lower left corner in a direction parallel to the toe wall and not perpendicular to the toe wall to prevent cumulative errors that affect the laying quality.
6、将联锁砖铺设上沿墙内，砌筑上沿墙，使得上沿部分联锁砖与上沿墙锚固，进行联锁砖面层色彩处理时，联锁砖表面浮灰及其他杂物、污染，如需水洗时，可用水冲洗，等水干后即可进行色彩处理。
6. Lay interlocking bricks into the upper edge wall, and build the upper edge wall so that the upper edge part of the interlocking bricks are anchored to the upper edge wall. When conducting color treatment for the surface layer of the interlocking bricks, remove the floating ash and other debris and pollution on the surface of the interlocking bricks. If it is necessary to wash with water, it can be washed with water, and the color treatment can be carried out after the water is dry.
7、用干砂、碎石或者土填充砖孔和接缝。
7. Fill brick holes and joints with dry sand, crushed stone, or soil.
8、为形成转角或者直边，可用无齿锯切割护坡砖以得到相应的规格和角度。
8. To form a corner or straight edge, a toothless saw can be used to cut the slope protection brick to obtain the corresponding specifications and angles.
护坡砖正确的施工流程相关内容就讲解到这里了，您对此有怎样的疑惑或者需求，就来我们网站http://www.longyuejiancai.com咨询了解吧！
That's all about the correct construction process for slope protection bricks. If you have any doubts or needs about this, please come to our website http://www.longyuejiancai.com Consult and understand!
